NDD 2500-2 EASYONE® AIR SPIROMETRY SYSTEM
NDD 2500-2 EASYONE® AIR SPIROMETRY SYSTEM
NDD EASYONE® AIR SPIROMETRY SYSTEM, Calibration-Free
EasyOne Air can be trusted in various locations and environments to perform reliably.
- Reliable design tried and tested at large screening events
- Extremely robust TrueFlow™ measurement technology
- Performs up to 100 complete tests with one battery charge
- Proven completely calibration-free device
Connectivity to Printers, PCs and EMR
Easily integrate EasyOne Air into your existing clinical workflow. The device is equipped with Bluetooth and USB modules making connections to printers, a central database and EMR systems extremely easy and stable.
- Directly connect printers via USB or print via EasyOne Connect
- Synchronize data via USB or Bluetooth
- Integrate into all major EMR/EHR systems via HL7, XML, GDT, or API
- Reference projects to all major EMR systems available on request
Standards & Recommendations:
Quality, Medical Devices & Electrical: IEC 60601-1, IEC 60601-1-2, IEC 62304, IEC 62366, ISO 13485, ISO 14971, ISO 26782, ISO 23747
FDA: 510(k) market clearance
Associations & Institutes: ATS/ERS 2005 spirometry standard, ATS/ERS 2019 spirometry standard, ATS/ERS 2022 interpretation strategies, NIOSH, OSHA, SSA Disability
Technical Spec:
Printing options: Direct to printer or with EasyOne Connect software
Data management: EasyOne Connect (SQLite, MS SQL Server)
Export: HL7, XML, GDT, with EasyOne Connect software
Data links: USB, Bluetooth
Test storage: >10,000 tests
Age range: Spirometry ≥4 years
Dimensions: 87 x 155 x 36 mm (H x W x D), 356 g, 3.4 x 6.1 x 1.4‘‘ (H x W x D), 13 oz
Device classification: Type BF applied part
Operating conditions: Temp 0 - 40 °C/ 32 - 104 °F, Rel. Humidity 5 - 90%, Atmosph. Pressure 700 - 1060 hPa
Power supply: Rechargeable lithum-ion battery, USB power supply
Rechargeable battery: Exchangeable, 3.6 VDC
