ABS ABT-HC-EFP-04 23.625" Undercounter Hazardous Location Freezer, 4 cu.ft., -15° to -25°C Temperature Range, Manual Defrost, 1 Solid Swing Door, 2 Shelves / 3 Baskets
In the fast-paced world of scientific and industrial laboratories, precision and safety are key. Our Hazardous Location Undercounter Freezers are engineered for use in environments where volatile or explosive conditions could exist. Crafted with ATEX and non-sparking components, these freezers are designed to keep you and your substances safe. These units meet NFPA and OSHA guidelines for Hazardous Location, Class 1, Division II, Groups A,B,C & D guidelines. Engineered with a microprocessor temperature controller, these units provide exceptional precision, recovery, and maintenance. You’ll also experience the power of natural hydrocarbon refrigerants through energy savings and a greener laboratory footprint—all while enjoying stellar system performance.*
Note: Please be aware that these units come without a plug and require hardwiring in conduit, ensuring a secure connection in your high-risk environment. Our freestanding models also require 4 inches of clearance for proper ventilation and safety.
Features
-
Hazardous Location Certified: This advanced unit fully meets rigorous NFPA and OSHA safety standards for Class 1, Division II, Groups A, B, C, and D hazardous environments.
-
Spark-Free Compliance: Engineered utilizing premium ATEX-rated and non-sparking components to eliminate any risk of internal electrical ignition inside the storage chamber.
-
Microprocessor Precision: Features an intelligent microprocessor controller paired with an external digital display to ensure highly accurate temperature monitoring and quick thermal recovery.
-
Eco-Friendly Performance: Utilizes natural R600a hydrocarbon refrigerant, lowering energy consumption and supporting a greener lab footprint while delivering stellar cooling power.
-
Industrial Security: Outfitted with a heavy-duty keyed door lock and a robust magnetic door gasket to secure sensitive contents and prevent accidental temperature leaks.
-
Maximum Security Wiring: Intentionally built without a standard plug to mandate secure, hardwired installation via dedicated conduit for high-risk regulatory environments.
Product Specifications
| Product Number | ABT-HC-EFP-04 |
| Capacity | 4 Cu. Ft. |
| Door Type | One Solid Swing Door |
| Interior Storage | Two Fixed Shelves + Three Removable Baskets |
| Security | Keyed Door Lock |
| Gasket Type | Magnetic Door Gasket for Positive Seal |
| Leveling Mechanism | Leveling Legs |
| Exterior Material | White Powder Coated Steel |
| Insulation Type | EPA Compliant High Density Foamed-in-Place Urethane |
| Refrigerant Type | Hydrocarbon, Natural R600a |
| Defrost Method | Manual Defrost |
| Temperature Controller | Microprocessor Temperature Controller |
| Temperature Display | Digital Temperature Display |
| Alarms | Audible/Visual High & Low Temp Alarms, Remote Alarm Contacts |
| Operating Temp Range | -15°C to -25°C |
| Exterior Dimensions (WxDxH) | 23 5/8″ x 23 5/8″ x 32 1/4″ |
| Electrical Requirements | 115V, 60Hz, 1.4 Amps |
| Wiring Requirement | No Plug; Must be Hardwired in Conduit |
| Product Net Weight | 91 lbs. |
| Shipping Weight | 118 lbs. |
| Certifications & Compliance | ETL Listed, Meets NFPA/OSHA Class 1 Div II Groups A,B,C,D |
| Warranty | Two Year Parts and Labor Warranty |
