ABS PH-ABT-NSF-UCBI-0404-ADA-LH 23.875" Undercounter Vaccine Refrigerator w/ NSF/ANSI 456, Left Hinged, Built-in, 4.6 cu.ft., 1° to 10°C Temperature Range, Cycle Defrost, 1 Solid Swing Door, 3 Shelves, ADA Compliant
These premier built-in undercounter refrigerators are designed in accordance with the NSF/ANSI 456 Standard for Vaccine Storage. Refrigerators protect pharmaceuticals at optimal temperatures, preventing waste and allowing for peak delivery.
The ADA compliant, solid door refrigerators utilize microprocessor controllers and feature temperature alarms, remote alarm contacts, and probe access ports with included probes. American Biotech Supply Vaccine Storage Refrigerators utilize HFC-free refrigerant for environmental health and energy efficiency.
Features
-
NSF/ANSI 456 Vaccine Certified: Independently tested and certified to comply with the highest standard for vaccine safety, guaranteeing total compliance for CDC and VFC storage protocols.
-
ADA-Compliant Profile: Features a space-saving, low-profile exterior height of 31 15/16 inches tailored precisely to slide under standard ADA-regulated counters and modern medical workstations.
-
Forced-Air Uniformity: Utilizes a patent-pending front-breathing forced-air management system that maintains an ultra-tight temperature uniformity of +/- 0.8 degrees Celsius, eliminating hazardous localized cold or warm pockets.
-
Rapid Thermal Recovery: Engineered to recover optimal storage temperatures under 4.8 minutes even after sustained 3-minute door openings, protecting sensitive biologics from heat-spikes.
-
Advanced Smart Controller: Outfitted with a parametric microprocessor controller displaying a 0.1 degree Celsius LED resolution, integrated state-switching remote alarm contacts, and automated high/low warnings.
-
Automated Access Integration: Built-in physical and digital structures seamlessly support industry-leading automated dispensing integrations including Pyxis, Omnicell, and Acudose Rx.
-
Extended Commercial Warranty: Backed by an industry-leading administrative security framework including a 2-year full parts and labor package alongside an exclusive 5-year compressor coverage.
Product Specifications
| Model Number | PH-ABT-NSF-UCBI-0404-ADA-LH |
| Storage Capacity | 4.6 cu. ft. Gross Volume |
| Exterior Dimensions (W x D x H) | 23 7/8″ x 24 3/8″ x 31 15/16″ |
| Temperature Range | 1°C to 10°C |
| Cabinet Temperature Uniformity | +/- 0.8°C |
| Cabinet Temperature Stability | +/- 1.2°C |
| Defrost Type | Cycle Defrost |
| Door Configuration | 1 Solid Swing Door, Left Hinged (Non-Reversible) |
| Door Features | Self-Closing, Magnetic Sealed Gasket, Keyed Lock |
| Shelving System | 3 Shelves (2 Adjustable / 1 Fixed) with Rear Guard Rails |
| Airflow Management | Forced Air Technology (Patent Pending) |
| Access Control Compatibility | Pyxis®, Omnicell®, and Acudose Rx® Compatible |
| External Probe Access | Rear Wall Port (1/2″ Diameter) |
| Agency Listings & Certifications | Certified to NSF/ANSI 456 Standard for Vaccine Storage |
| Safety & Safety Listings | UL, C-UL, ETL, C-ETL Listed; Certified to UL471 Standard |
| Refrigerant Type | Hydrocarbon Refrigerant Safety (EPA Compliant) |
| Product Net Weight | 100 lbs. |
| Shipping Weight | 140 lbs. |
| Electrical Requirements | 110-120V AC, 15 A Minimum (1.74 Amps Rated) |
| Power Plug Type | NEMA 5-15 Plug, 8 to 10 ft Cord with Warning Label |
| Warranty Structure | 2-Year Parts & Labor; 5-Year Compressor Warranty |
