Basic American M6AF35 Matrix 6200 APS Full-Electric Long-Term Care Bed – 35" or 42" Deck Width, Premium, Heavy-Duty Full-Electric Long-Term Care Bed
Matrix6200 APS is a premium, heavy-duty full-electric long-term care bed engineered for safe, comfortable, and reliable patient care in nursing homes, rehab centers, hospitals, and long-term care facilities. Manufactured in Fond du Lac, Wisconsin (USA) by Basic American / Graham-Field, it features sealed ball bearings in joints for smooth, quiet, maintenance-free movement, SilverSolutions antimicrobial powder coating for surface protection, and a robust steel frame with a grid-style sleep deck for superior mattress support (no sag or bottoming out with heavier patients). The bed offers fully electric three-function positioning (head, foot, Hi-Lo) via pendant control, synchronized Hi-Lo motors to keep the bed level, battery backup for dependability during power failures, and deluxe casters (standard or pedal-lock options). Available in 35" or 42" deck widths with adjustable length (80"–84"), it supports up to 400 lb patient weight / 450 lb total capacity (evenly distributed).
Features:
- Made in the USA — minimal lead times, quality craftsmanship, fast response to customer needs
- SilverSolutions antimicrobial powder coating — provides continuous surface protection against bacteria
- Sealed ball bearings — seamless, noiseless, maintenance-free joint movement
- Grid sleep deck — sturdy, no-sag surface with cross braces for excellent support
- Fully electric 3-function operation — head, foot, and Hi-Lo adjustment; quiet and energy-efficient
- Synchronized Hi-Lo motors — keep bed level during height changes
- Battery backup standard — ensures operation during power outages
- Deluxe caster options — 5" casters (standard swivel or pedal-lock for easy floor locking)
- ANSI/AAMI ES60601 certified — tip stability, load capacity (2× operating), roll clearance, splash-proof electronics
- CMS Emergency Preparedness certified — transport-ready through doorways/hallways
- Optional plug-and-play digital electronics — future upgrades (Trend/Rev Trend, Chair, underbed light, USB charger)
- Optional intuitive side rails & head/footboards — sold separately
- High-strength truss frame — durable powder-coated finish
- Simple assembly — no special tools required
- Grounded bed with right-angle hospital-grade plug — added safety for staff and residents
Specifications:
| Specification | 35" Deck Models | 42" Deck Models |
|---|---|---|
| Deck Width | 35" | 42" |
| Deck Length (Adjustable) | 80" – 84" | 80" – 84" |
| Operation | Full-electric (head, foot, Hi-Lo) – 3-function standard | Full-electric (head, foot, Hi-Lo) – 3-function standard |
| Height Range (Deck Level) | Min. 8.95" – Max. 27" | Min. 8.95" – Max. 27" |
| Patient Weight Capacity | 400 lbs | 400 lbs |
| Total Weight Capacity | 450 lbs (patient + mattress + rails + accessories) | 450 lbs (patient + mattress + rails + accessories) |
| Casters | 5" Deluxe (standard swivel or pedal-lock) | 5" Deluxe (standard swivel or pedal-lock) |
| Intended Use | Long-term care, bariatric patient care, rehab | Long-term care, bariatric patient care, rehab |
| Warranty | Main Frame & Welds: 15 years Control Box & Actuator Motors: 4 years Hand Control Pendant & Cabling: 3 years Head & Footboards: 1 year All Other Components: 1 year | Same as 35" models |
Variants:
| Variant Name | Description | SKU | Deck Width | Caster Type | Notes / Shipping Weight (Approx.) |
|---|---|---|---|---|---|
| Matrix6200 APS – 35" Deck | Bed only – standard swivel casters | M6AF35 | 35" | Standard swivel |
estimated 250–300 lbs packaged |
| Matrix6200 APS – 35" Deck w/ Pedal-Lock | Bed only – pedal-lock casters (central locking) | MZ6AF35 | 35" | Pedal-lock |
estimated 250–300 lbs packaged |
| Matrix6200 APS – 42" Deck | Bed only – standard swivel casters | M6AF42 | 42" | Standard swivel |
estimated 250–300 lbs packaged |
| Matrix6200 APS – 42" Deck w/ Pedal-Lock | Bed only – pedal-lock casters (central locking) | MZ6AF42 | 42" | Pedal-lock |
estimated 250–300 lbs packaged |
Contents:
| Description | Quantity |
|---|---|
| Matrix6200 APS Bariatric Full-Electric Bed Frame | 1 |
| Two-Piece Split Steel Frame | Included |
| Solid Pan-Style Sleep Deck (35" or 42" width) | Included |
| Pendant Control (3-function standard) | Included |
| Deluxe 5" Total-Lock & Steer-Lock Casters (or pedal-lock per variant) | Included |
| Battery Backup System | Included |
| User Manual & Assembly Guide | 1 |
| Carton Packaging | 1 |
General Information:
- Condition: New – Made to order or in-stock availability varies (contact for current status). Drop ships directly from vendor (Graham-Field). Not cancellable, not returnable once processed.
- Shipping: Very heavy item (estimated 250–300 lbs packaged) – freight intensive. Freight shipping required. Calculated at checkout (notify customer of freight exception).
- Installation Tips: Simple assembly – designed for caregiver ease. Professional setup recommended for clinical use. Rails, boards, scale, and other accessories sold separately.
- Cleaning: Wipe frame and deck with mild soap or hospital-grade disinfectant; powder-coated finish with SilverSolutions resists corrosion and bacteria.
- Permissible Ambient: Indoor use; avoid extreme temperatures.
- Applications: Bariatric patient care, long-term care, rehab, pressure ulcer prevention, expandable width/length for custom fit, caregiver-assisted positioning. Volume discounts available – call or email for orders of 10+ units.
