| Overview | |
|---|---|
| Product Name | Body-Solid F500B Fusion Personal Trainer (210 lb. Stack) |
| Product Model | F500B/2 |
| Brand / Product Line | Body-Solid Fusion Series |
| Product Category | Hybrid Multi-Station / Personal Trainer Gym |
| Commercial Rating | In-Home Lifetime / Light Commercial Rated |
| Weight Stack Configuration | 210.00 lbs. (95.25 kg) Selectorized Stack |
| Optional Stack Upgrade | Upgradable to 310 lb. Stack |
| Frame Construction | 50mm x 100mm 11-Gauge Oval Steel Tubing with 6mm Support Plates |
| Frame Finish | Scratch-Resistant Black Powder Coat Finish |
| Ergonomics | Gas-Assisted Telescoping Seat Post & Adjustable Backrest |
| Warranty (In-Home Lifetime) | Frame & Welds: Lifetime; Bushings & Hardware: Lifetime; Pads, Cables, & Grips: Lifetime |
| Warranty (Light Commercial) | Frame & Welds: Lifetime; Bushings & Hardware: 3 Years; Pads, Cables, & Grips: 1 Year |
| Station Breakdown | |
| Multi-Press Hub | 4-Position Press Arm for Bench Press, Incline Press, Decline Press, Shoulder Press, Chest-Supported Row |
| Functional Training Arms | 160° Synchronized Articulating Arms (16 Positions) for Cable Flys, Wood Chops, Ab Crunches |
| High Pulley & Lat Station | Lat Pulldowns, Triceps Extensions, Overhead Cable Movements |
| Leg Developer | Integrated Leg Extension Station with Pivoting Rollers |
| Optional Attachments (Sold Separately) | Fusion Leg Press (FLP), Multi-Hip (FMH), Weight-Assisted Dip/Chin (FCDWA) |
| Dimensions & Weights | |
| Assembled Product Dimensions | 76.00" L x 48.00" W x 83.00" H (1,930.40 mm L x 1,219.20 mm W x 2,108.20 mm H) |
| Assembled Total Weight | 526.00 lbs. (238.59 kg) |
| Total Shipping Weight | 586.00 lbs. (265.81 kg) |
| Shipping Configuration | 4 Boxed Components + 4 Boxes of PP10 Weight Plates (50.00 lbs. / 22.68 kg each) |
20% off
Fast & Reliable Shipping
Typically 1-3 Business Days
Regulatory Compliant
Registered & Certified Medical Equipment
Support
Need help?
Fast & Reliable Shipping
Typically 1-3 Business Days
Regulatory Compliant
Registered & Certified Medical Equipment
Support
Need help?
Body-Solid F500B/2 Fusion Personal Trainer (210 lb. Stack), Standard 210 lb. Weight Stack, 160° Articulating Functional Arms, 4-Position Multi-Press Hub, Integrated Leg Extension Station, Heavy-Duty 11-Gauge Mainframe
The Body-Solid F500B Fusion Personal Trainer (SKU: F500B/2) is a versatile hybrid home gym system designed to combine traditional strength training with dynamic functional movement vectors. Equipped with a standard 210 lb. selectorized weight stack column, the F500B supports more than 60 full-body exercises within a compact footprint. Engineered for high-end home fitness spaces and light commercial facilities, it features an 11-gauge oval steel mainframe and a modern matte black finish.
At the heart of the F500B's functional versatility are its 160° synchronized articulating functional training arms. With 16 adjustment positions (in 20° increments), these arms allow users to engage stabilizer muscles and perform cable flys, rotational core movements, and sport-specific exercises. The gym also includes a 4-position multi-press hub with ergonomic grips, an integrated leg extension station, gas-assisted seat adjustments, and support for modular add-on attachments.
Features:
- Standard 210 lb. Weight Stack: Fitted with smooth nylon bushings for quiet, fluid motion; upgradable to a 310 lb. weight stack column for increased resistance.
- 160° Articulating Functional Arms: Synchronized functional training arms adjust up to 160 degrees in 20-degree increments (16 positions) for rotational, core, cable fly, and athletic movement patterns.
- 4-Position Multi-Press Hub: Adjustable press arm with multi-position handles supports chest press, incline press, decline press, shoulder press, and chest-supported rows.
- Integrated Leg Extension Station: Lower-body station featuring self-aligning pivoting rollers to maintain constant quadriceps engagement throughout the exercise.
- High Pulley & Lat Station: Wide-groove top pulley design provides smooth mechanics for lat pulldowns, triceps pressdowns, and upper body isolations.
- Gas-Assist Seating Ergonomics: Chrome-plated telescoping seat post with gas-assisted quick adjustment and an adjustable backrest ensure proper biomechanical alignment.
- Heavy-Duty 11-Gauge Mainframe: Built with 50mm x 100mm (2" x 4") 11-gauge oval steel tubing reinforced by 6mm thick steel plates and fitted with high-density foam grips.
- Modular Attachment Support: Formed to integrate seamlessly with optional attachments, including the Fusion Leg Press (FLP), Multi-Hip Station (FMH), and Weight-Assisted Dip/Chin-Up Station (FCDWA).
- Comprehensive Lifetime Warranty: Backed by Body-Solid's In-Home Lifetime Warranty and Light Commercial Warranty covering frame, welds, bushings, pads, and cables.
Specifications:
