| Overview | |
|---|---|
| Product Name | Body-Solid SBL460 Freeweight Leverage Gym Package |
| Product Model | SBL460P4 |
| Brand / Product Line | Body-Solid Freeweight Leverage Gym Series |
| Product Category | Plate-Loaded Multi-Station Leverage Gym |
| Commercial Rating | In-Home Lifetime / Light Commercial Rated |
| Resistance Type | Standard & Olympic Plate-Loaded (Weight Plates Sold Separately) |
| Mainframe Construction | 3" x 3" 10-Gauge and 11-Gauge High-Tensile Steel Frame |
| Bearing System | Commercial-Grade Sealed Ball Bearings & Pillow Block Bearings |
| Pad Type | Ultra-Dense DuraFirm™ Upholstery |
| Package Included Components | |
| SBL460 | Main Leverage Base Frame Unit |
| FID46 | Heavy-Duty Flat / Incline / Decline Utility Bench |
| LSA50 | Dedicated Leverage Squat & Calf Raise Attachment |
| Optional Attachments & Add-Ons | |
| WT46 | Olympic Weight Storage Tree |
| SCB46 | Squat / Calf Block Attachment |
| Dimensions & Weights | |
| Assembled Overall Package Dimensions | 149.00" L x 100.00" W x 83.00" H (3,784.60 mm L x 2,540.00 mm W x 2,108.20 mm H) |
| Alternative Layout Working Dimensions | 107.00" L x 126.00" W x 83.00" H (2,717.80 mm L x 3,200.40 mm W x 2,108.20 mm H) |
| Assembled Total Weight | 630.00 lbs. (285.77 kg) |
| Package 1 Dimensions | 52.56" L x 16.54" W x 10.24" H (1,335.02 mm L x 420.12 mm W x 260.10 mm H); Gross Weight: 111.10 lbs. (50.39 kg) |
| Package 2 Dimensions | 52.95" L x 20.28" W x 7.09" H (1,344.93 mm L x 515.11 mm W x 180.09 mm H); Gross Weight: 107.80 lbs. (48.90 kg) |
| Package 3 Dimensions | 37.20" L x 34.84" W x 7.28" H (944.88 mm L x 884.94 mm W x 184.91 mm H); Gross Weight: 103.40 lbs. (46.90 kg) |
| Package 4 Dimensions | 64.76" L x 21.06" W x 7.09" H (1,644.90 mm L x 534.92 mm W x 180.09 mm H); Gross Weight: 126.70 lbs. (57.47 kg) |
| Warranty Structure | |
| In-Home Warranty | Frame, Welds, Bushings, Bearings, Hardware, & Pads: Lifetime |
| Commercial Warranty | Frame & Welds: Lifetime; Bushings & Hardware: 3 Years; Pads, Rollers, & Grips: 1 Year |
Typically 1-3 Business Days
Registered & Certified Medical Equipment
Need help?
Typically 1-3 Business Days
Registered & Certified Medical Equipment
Need help?
Body-Solid SBL460P4 Freeweight Leverage Gym Package, Heavy-Gauge Steel Frame, Built-in Safety Catch System, DuraFirm Heavy-Duty Padding
The Body-Solid Freeweight Leverage Gym Package (SBL460P4) is an extra heavy-duty plate-loaded strength system designed to deliver raw freeweight feel with maximum safety. By substituting traditional cables and pulleys with rigid steel leverage arms articulating on commercial-grade pillow block bearings and bronze bushings, the SBL460 allows lifters to push heavy loads to failure without the need for a spotter or the fear of getting pinned.
This complete package configuration (#SBL460P4) includes the main Leverage Gym Base Frame (#SBL460), the Flat/Incline/Decline Bench (#FID46), and the Leverage Squat Attachment (#LSA50). Constructed from 3" x 3" 10-gauge and 11-gauge high-tensile steel with four-side welded reinforcement plates, this system handles maximum weight capacities for bench pressing, squatting, shoulder pressing, lat pulldowns, and row movements in both home and commercial fitness facilities.
Features:
- Plate-Loaded Leverage Technology: Replicates natural free-weight movement paths and resistance curves while providing the built-in safety catches of selectorized machines.
- Included Utility Bench & Squat Module: Ships complete with the FID46 Flat/Incline/Decline Adjustable Bench and LSA50 Leverage Squat Attachment.
- Heavy-Gauge Steel Frame: Constructed from extra-large 3" x 3" 10-gauge and 11-gauge high-tensile steel with all-4-side welded joint construction and heavy reinforcement plates.
- Commercial Pillow Block Bearings: Smooth rotation on all main pivot points utilizing precision sealed ball bearings and oversized self-lubricating bronze bushings to eliminate play under heavy loads.
- Built-in Safety Catch System: Integrated safety stops at every press and squat station allow users to safely train to muscular failure without a spotter.
- DuraFirm™ Heavy-Duty Padding: Ultra-thick, high-density foam padding covered in tear- and sweat-resistant upholstery guaranteed never to bottom out.
- Scratch-Resistant Powder Coat: Electrostatically applied textured powder-coat finish resists chips, scrapes, and rust while hiding fingerprints.
- Body-Solid Lifetime Warranty: Backed by Body-Solid's In-Home Lifetime Warranty covering frame, welds, bearings, hardware, and DuraFirm pads.
Specifications:
