Hoshizaki KM-81BAJ 17.75″ Crescent Cuber Icemaker, Air-Cooled, Stainless Steel, Built in Storage Bin, 86 lbs per Day, EverCheck™ Alert System, R-134a Refrigerant, ENERGY STAR Qualified
The KM-81BAJ is capable of producing approximately 86 lbs of crescent cubed ice. This Undercounter Air-cooled, Built in Storage Bin icemaker stores up to 38 lbs of ice*, which makes it ideal for small bars, hotel lobbies, and office break rooms. It features the CycleSaver™ design and includes the EverCheck™ alert system making the unit simple to maintain. The KM-81BAJ requires a Single phase, 115v/60/1, 6.5 ft cord with NEMA 5-15 plug electrical connection. Front in, front out airflow. ENERGY STAR® qualified. Please consult the Specification Sheet for additional details.*Rated in accordance with AHRI Standard 820(I-P). Capacity based on 100% of total volume x 30 lb/ft3 average density of ice.
Features
- Individual crescent cube
- Stainless steel evaporator
- CycleSaverTM design
- Up to 78 lbs. of ice production per 24 hrs
- Built-in storage capacity of 1.3ft3/38 lbs.
- Durable stainless steel exterior
- Front-in, front-out airflow with removable air filter
- Slide in door
- Power switch accessible without panel removal
- Built-in installation possible
- 6.5 ft. (2000 mm) power cord with NEMA 5-15P plug
- EverCheckTM alert system
- R-134a Refrigerant
- Optional Drain pump assembly - HS-5061
Product Specifications
| Specification | Details |
| Model Number | KM-81BAJ |
| Ice Style | Crescent Cube |
| Condenser Cooling | Air-Cooled |
| Daily Production Capacity | Up to 86 lbs. / 24 hours (AHRI: 52 lbs. at 90°F/70°F) |
| Built-in Storage Bin Capacity | Up to 38 lbs. (1.3 cu. ft.) |
| Exterior Dimensions (W x D x H) | 17.75" W x 24" D x 39" H |
| Net Weight | 92 lbs. |
| Shipping Weight | 125 lbs. |
| Ambient Temperature Range | 45°F – 100°F (7.2°C – 38.9°C) |
| Water Temperature Range | 45°F – 90°F (7.2°C – 32.2°C) |
| Water Pressure Range | 10 – 113 psig |
| Electrical Requirements | 115V / 60Hz / 1-Phase (NEMA 5-15P cord included) |
| Amperage / Max Fuse Size | 3.5 Amps / 15 Amp Max Fuse |
| Refrigerant Type & Charge | R-134a (7.1 oz / 201 g) |
| Exterior Finish | Durable Stainless Steel |
| Certifications & Compliance | AHRI, ENERGY STAR®, ETL Sanitation, NSF, cETLus, ADA Compliant |
