Performance

• Microprocessor PID control / Temperature calibration / Automatic tuning.
• Advanced performance of low and high temperature and humidity control, achieved by adapting the humidification tank exterior to the chamber, added benefit for long term test.
• Water recycling system reduce water consumption for longer operation.
• Air-tight door closure with perfect sealed packing.
  - Heat-resistant silicone packing completely blocks high heat leakage from the inner chamber.
  - Two-point door latch also enhances tightness to door closure.
• Energy efficiency is achieved by optimization of the insulation system.
  - Even if the unit is operating at max. temperature, the surface of the unit doesn’t allow high temperatures of over 60℃.

Safety

• Built in door lock with a key.
• Automatic shut off after overheat alarm.
• Low and empty water level alarm.
• Power supply leakage breaker.
• Over current protection.
• Open door alarm.

Convenience

• Spacious chamber volume with a maximum capacity of 1500L.
  - Various volume sizes, available to suit any users’ need.
• Corrosion resistance stainless steel chamber and electric polished humidification tank.
• Maintenance of water supply are easily performed with a front water tank.
  - Portable water container makes supplying water convenient.
• Water supply during operation is also available for long term test purposes.
• Direct water system provides user great convenience when performing long-term tests. (optional)
• Clear observation of samples.
  - Tempered glass door with built in heating wire.
  - Energy efficient, long life span LED lighting.
  - Wider view, inner glass door is available for monitoring of samples. (optional)
• Cable port for introduction of external probes or wires.
  - 50mm diameter cable port comes standard on the left side of the unit.
  - Additional 50mm or 80mm diameter cable ports, custom ordered. (optional)
• Casters for easy mobility during installation or relocation.
• User friendly LCD controller.
  - Colorful interactive touch type LCD controller.
  - Set point temperature and present temperature are clearly shown together on display.
  - Sufficient programmable control support.
  - Operating progress can be shown in graph mode for better data understanding.
  - Automatic start/stop can be programmed for unattended operations.
  - Display indicates abnormal temperature changes or power failures.
  - Selective bilingual language support.
  (Korean / English or English / Chinese, selectable only when placing an order)
  - Temperature and other operating parameters can be recorded using a six channel digital recorder.(optional)
• Computer interface.
  - RS-485 communication port (optional) enables connection up to maximum 32 units. Simultaneous monitoring and operating of multiple units is an available feature.
  - Program patterns are simple to set with the use of our software.
  - Easy to check status of real-time operations. Graph data supports easy understanding.
  - Storage and documentation of programs.
  - Data with saving capabilities in excel and text format.
  - Storage of program information, backup of value settings, recovery, and temperature values.
  - RS-232 communication port as standard offer.

Specifications
