| Overview | |
|---|---|
| Product Name | Body-Solid ProDual Leg Press and Calf Extension (210 lb. Stack) |
| Product Model | DCLPSF |
| Brand / Product Line | Body-Solid ProDual Series |
| Product Category | Commercial Selectorized Leg Press / Calf Machine |
| Commercial Rating | Full Commercial / Light Commercial / In-Home Rated |
| Resistance System | 210 lb. Selectorized Weight Stack (310 lb. Upgrade Available) |
| Effective Resistance Ratio | 1:2 Cable Linkage Ratio (Provides up to 420 lbs. of effective resistance) |
| Pulleys & Bearings | Fiberglass-Reinforced Nylon Pulleys with Sealed Ball Bearings & Oversized Pillow Block Alignment |
| Frame Construction | Continuous 4-Side Welded 11-Gauge High-Tensile Steel |
| Finish | Electrostatically Applied Powder Coat Finish |
| Modular Integration | Compatible with ProDual 3-Stack & 4-Stack Multi-Gym Frames |
| Target Exercises & Muscle Groups | |
| Primary Exercises | Seated Leg Press, Calf Extensions, Single-Leg Press |
| Target Musculature | Quadriceps (Vastus Lateralis, Rectus Femoris, Vastus Medialis), Gluteus Maximus, Hamstrings, Gastrocnemius, Soleus |
| Dimensions & Weights | |
| Assembled Unit Dimensions | 82.00" L x 37.00" W x 77.00" H (2,082.80 mm L x 939.80 mm W x 1,955.80 mm H) |
| Alternative Frame Spec Dimensions | 78.00" L x 41.00" W x 77.00" H (1,981.20 mm L x 1,041.40 mm W x 1,955.80 mm H) |
| Assembled Product Weight | 549.00 lbs. (249.03 kg) |
| Shipping & Packaging Specifications | |
| Package 1 Dimensions | 56.30" L x 20.90" W x 10.40" H (1,430.00 mm L x 530.00 mm W x 265.00 mm H) |
| Package 1 Gross Weight / Volume | 105.00 lbs. (47.63 kg) / 7.09 ft³ (0.201 m³) |
| Package 2 Dimensions | 33.10" L x 25.60" W x 14.20" H (840.00 mm L x 650.00 mm W x 360.00 mm H) |
| Package 2 Gross Weight / Volume | 105.20 lbs. (47.72 kg) / 6.94 ft³ (0.197 m³) |
| Package 3 Dimensions | 82.70" L x 35.00" W x 9.10" H (2,100.00 mm L x 890.00 mm W x 230.00 mm H) |
| Package 3 Gross Weight / Volume | 179.00 lbs. (81.19 kg) / 15.18 ft³ (0.430 m³) |
| Warranty Structure | |
| Commercial Warranty | Lifetime Frame & Welds | 3 Years Bushings, Bearings, & Hardware | 1 Year Pads, Rollers, Cables, & Grips |
| In-Home Warranty | Lifetime Coverage on Frame, Welds, Bushings, Bearings, Hardware, Pads, & Cables |
Pro ClubLine DCLPSF ProDual Leg Press and Calf Extension (210 lb. Stack)
Typically 1-3 Business Days
Registered & Certified Medical Equipment
Need help?
Typically 1-3 Business Days
Registered & Certified Medical Equipment
Need help?
Pro ClubLine DCLPSF ProDual Leg Press and Calf Extension, Standard 210 lb. Selectorized Stack, Ergonomic 12-Position Recumbent Seat
The Body-Solid ProDual Leg Press and Calf Extension (SKU: DCLPSF) delivers a comprehensive lower-body strength training solution designed to target and build the quadriceps, hamstrings, glutes, and calves. Engineered with an advanced recumbent seating structure, this machine significantly reduces spinal compression while guiding users through a biomechanically correct path of motion.
Equipped with a standard 210 lb. selectorized weight stack and a specialized 1:2 cable pulley linkage that doubles effective resistance, the DCLP generates up to 420 lbs. of smooth pressing power. Designed for commercial facilities, personal training studios, and premium home gyms, the DCLP can operate as an independent single-station unit or integrate seamlessly as a modular component on ProDual 3-Stack and 4-Stack multi-gym systems.
Features:
- Standard 210 lb. Selectorized Stack: Standard weight stack configuration with a 1:2 weight-to-resistance ratio, generating up to 420 lbs. of effective resistance for lower-body development (expandable via the optional 310 lb. stack upgrade).
- Ergonomic 12-Position Recumbent Seat: Highly adjustable DuraFirm™ back pad with 12 locking positions accommodates users of all sizes and minimizes lower-back and spinal strain during heavy lifts.
- Biomechanical Four-Bar Linkage: Oversized pillow-block and sealed ball bearings ensure precision alignment and friction-free movement throughout the entire range of motion.
- Extra-Wide Non-Skid Press Plate: Features a broad rubber-matted pressing surface with an integrated two-position design for comfortable placement during both leg press and calf extension movements.
- Integrated Stabilizing Handgrips: Conveniently placed side handles provide enhanced torso stabilization and support during maximum capacity pressing.
- Heavy-Gauge Steel Frame Construction: Built with continuously four-sided welded 11-gauge high-tensile strength steel tubing (2"x2", 2"x3", and 2"x4") finished with a durable, scratch-resistant electrostatic powder coating.
- Tear-Resistant DuraFirm™ Padding: Extra-thick, high-density foam padding provides maximum lumbar support without bottoming out under heavy loads.
- Modular Multi-Gym Compatibility: Functions as an independent station or connects into Body-Solid ProDual 3-Stack and 4-Stack gym frame configurations.
Specifications:
