USA Lab ECF-17.12-40-E EcoChill 17.12 Cu.Ft. -40°C Chest Freezer, Digital Display, Heavy-Duty Mobility, Castors Included, Energy Efficient & Eco-Friendly, Stainless Steel
Introducing our EcoChill Series Digital Display Chest Freezer — a reliable, budget-friendly solution for food service, clinical, and laboratory storage. With a working range of −20°C to −40°C, EcoChill preserves temperature-sensitive items with stable, uniform performance.
Energy-efficient R290 refrigeration, PURF insulation, and direct-cooling architecture reduce power use without sacrificing pull-down speed. A microprocessor controller with a clear digital display makes setpoint changes and monitoring simple and precise.
Features
- Precision Temperature Control:
- Ultra-Low Cooling Range: Capable of maintaining consistent pull-down temperatures from -20°C down to -40°C, ensuring optimal preservation for sensitive biological samples, vaccines, reagents, and industrial materials.
- Digital Microprocessor Display: Features an intuitive LED/LCD control panel for real-time monitoring, precision calibration, and effortless temperature setting adjustments.
- Superior Thermal Insulation & Build Quality:
- Heavy-Duty Construction: Built with high-grade, corrosion-resistant stainless steel interior walls for rapid thermal transfer and effortless sanitation.
- High-Density Polyurethane Foam Insulation: Engineered with extra-thick, CFC-free insulation to minimize temperature loss, reduce compressor wear, and maintain internal coldness during power outages.
- Dual-Gasket Door Seal: Multi-layer magnetic door seals ensure a airtight closure to eliminate frost accumulation and cold air leakage.
- Eco-Friendly & High-Efficiency Refrigeration:
- R290 Natural Refrigerant: Utilizes eco-friendly hydrocarbon refrigerant (R290) with zero Ozone Depletion Potential (ODP) and extremely low Global Warming Potential (GWP).
- Commercial-Grade Compressor: High-torque compressor design delivers rapid pull-down times, quick temperature recovery after lid openings, and whisper-quiet operation.
- Comprehensive Safety & Sample Protection:
- Integrated Alarm Systems: Features audible and visual alerts for high/low temperature deviations, sensor failures, and power interruptions to protect critical inventory.
- Secure Key Lock: Built-in heavy-duty latch with a physical key lock prevents unauthorized access to high-value contents.
- Ergonomic & Practical Design:
- 17.12 Cu. Ft. Storage Capacity: Offers a spacious 485-liter interior layout designed to maximize sample storage density while maintaining uniform airflow.
- Heavy-Duty Caster Wheels: Equipped with 360-degree swivel casters (with front locking brakes) for seamless mobility and easy positioning across laboratory floors.
- Defrost Drain Port: Front-mounted drain outlet simplifies manual defrosting and cleaning maintenance procedures.
Specifications
| Cooling Method | Direct Cooling |
| Defrost | Manual |
| Refrigerant Type | R290 |
| Power Consumption | 3.45 kWh / 24 h |
| Noise | 55 dB |
| Ambient Temperature | 10℃ ~ 32℃ |
| Temperature Range | −20℃ ~ −40℃ |
| Compressor Brand / Qty | CUBIGEL / 1 |
| Condenser | Wire tube |
| Sensor | NTC |
| Temperature Controller | Microprocessor |
| Display | Digital display |
| Voltage / Frequency | 110/120 V 60 Hz |
| Power | 295 W |
| Current | 2.45 A |
| Inside Material | Stainless steel |
| Outside Material | Spray-coated steel |
| Insulation | PURF |
| Capacity (L / cu.ft) | 485 L / 17.12 cu ft |
| Net / Gross Weight | 124 / 138 kg (≈ 290 / 340 lb) |
| Exterior Size (W×D×H) (mm) | 1667 × 863 × 949 |
| Exterior Size (W×D×H) (in) | 67" × 33" × 38" |
| Interior Size (W×D×H) (mm) | 1455 × 525 × 665 |
| Interior Size (W×D×H) (in) | 57.2" × 20.7" × 26.5" |
| Package Size (W×D×H) (mm) | 1775 × 900 × 1050 |
| Package Size (W×D×H) (in) | 69.5" × 35.5" × 42" |
| CBM | 1.66 |
| 20GP / 40GP / 40HQ | 12 / 26 / 26 |
| Test Hole QTY / Diameter | 1 / 25 mm |
| USB Port | N/A |
| Remote Alarm Port | N/A |
| Alarms | High/Low Temp (Y), Power Failure (Y), Sensor Error (Y), Temp Controller Failure (Y), Low Battery (/), Filter Check (/), Condenser Clean (/), High Ambient Temp (/), Door Ajar (/) |
| Power Failure Backup (Alarm) | 12 h |
| Castor | Y |
| Accessories | Chart Recorder (Optional), Data Logger (Optional), CO₂ Backup (Optional), LN₂ Backup (Optional), Gloves (Optional) |
