Accucold ARG31PVBIADA-AFZ2PVBIADASTACKLHD 20" Wide Performance Series All-Refrigerator/Freezer Combination
Accucold ARG31PVBIADA-AFZ2PVBIADASTACKLHD 20" Wide Performance Series All-Refrigerator/Freezer Combination
Accucold ARG31PVBIADA-AFZ2PVBIADASTACKLHD 20" Wide Performance Series All-Refrigerator/Freezer Combination, Eco-Friendly (refrigerator)
Accucold offers innovative solutions to vaccine storage with our Performance Series stackable purpose-built refrigerator-freezer combinations designed to support meeting CDC/VFC/VFA guidelines.
Sized just under 20" wide, the ARG31PVBIADA-AFZ2PVBIADASTACKLHD combines the 2.83 cu.ft. ARG31PVBIADALHD auto defrost all-refrigerator with AFZ5PVBIADA all-freezer into one slim footprint using Accucold's StackRack. This ships in three boxes and requires some minor assembly upon delivery. Both units come with a left hand door swing.
The Pharma-Vac Performance Series is designed to meet the demanding needs of vaccine storage. Both units utilize a microprocessor temperature controller (refrigerator range: +2 to +8ºC; freezer range: -30 to -10ºC). The buffered temperature probe is encased in a glycol-filled bottle to better simulate temperature of the stored product, with an additional sensor that reads air temperature to ensure superior temperature control. The current and min/max temperature display is viewable in Celsius or Fahrenheit to the nearest tenth of a degree. The audible and visual temperature alarms sound if the units' interiors go out of range. Additional alarms include a power failure alert, door open alarm, and sensor failure alarm. Both units are equipped with remote alarm contacts in the rear and a 1/2" probe port on the right side to accept additional monitoring devices. The factory-installed antimicrobial handles are powder-coated with naturally occurring silver ions, which help to reduce the spread of germs, allowing for a safer, cleaner user experience. A hospital grade cord with 'green dot' plug is also included for added safety in high traffic areas.
Inside, the ARS32PVBIADA refrigerator utilizes adjustable cycle defrost operation to avoid temperature spikes. Optimized forced air cooling with an internal fan ensures excellent temperature stability and uniformity with rapid recovery after door openings. The adjustable plastic-coated wire shelves can be positioned at 1/2" increments to accommodate virtually any sized item. This unit includes LED internal lighting with an on/off rocker switch. The interior is constructed from white powder coated metal to ensure added durability and better temperature retention.
The refrigerator is designed to be stacked on top of the AFZ2PVBIADA, our Performance Series 2.47 cu.ft. all-freezer that utilizes static manual defrost operation. The freezer includes four adjustable plastic-coated wire shelves for flexible storage.
Features:
• Performance Series Refrigerator-Freezer Combination
• Purpose-built design
• +/-1ºC Variation
• Space-saving design
• Easy assembly
• Antimicrobial silver ion-coated handles
• Adjustable temperature
• Temperature alarms
• Remote alarm contacts
• Automatic defrost with adjustable cycle defrost (refrigerator)
• Manual defrost (freezer)
• Access ports
• Open door alarms
• Audible power failure alarms
• Sensor failure alarms
• Password protection
• Microprocessor control panels
• Resettable min/max displays
• Factory-installed locks
• Adjustable plastic-coated wire shelves for improved circulation
• Hospital grade cord with 'green dot' plug
• Interior light
• Magnetic door gaskets
• Extended warranty
• Eco-Friendly (refrigerator)
• Usage stickers
• Versatile design
• 100% CFC free
• CARB Compliant
Specifications:
|
Overview
|
|
|---|---|
| Nominal Height | 64.0" (163 cm) |
| Height of Cabinet | 64.0" (163 cm) |
| Nominal Width | 20.0" (51 cm) |
| Width | 19.75" (50 cm) |
| Width with Door Open | 20.25" (51 cm) |
| Nominal Depth | 23.0" (58 cm) |
| Depth | 22.63" (57 cm) |
| Depth with Handle | 24.38" (62 cm) |
| Depth with door at 90° | 41.25" (105 cm) |
| Capacity | 5.3 cu.ft. (150 L) |
| Door | Glass |
| Cabinet | White |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Voltage/Frequency | 115 V AC/60 Hz |
| Parts & Labor Warranty | 2 Years |
| Compressor Warranty | 5 Years |
| UPC | 761101104126 |
|
Refrigerator-Freezer
|
|
| Door Swing | LHD |
| Reversible | No |
| Adjustable Shelves | Yes |
| Interior Light | Yes |
| Refrigerator - Interior Height | 24.0" (61 cm) |
| Refrigerator - Interior Width | 16.0" (41 cm) |
| Refrigerator - Interior Depth | 15.0" (38 cm) |
| Refrigerator - Capacity | 2.83 cu.ft |
| Refrigerator - Shelf Type | Wire |
| Refrigerator - Shelf Qty | 4 |
| Refrigerator - Temperature Range | 2 to 8ºC |
| Refrigerator - Refrigerant Type | R600a |
| Refrigerator - Refrigerant Amount | 1.41 oz. |
| Freezer - Interior Height | 22.0" (56 cm) |
| Freezer - Interior Width | 14.25" (36 cm) |
| Freezer - Interior Depth | 15.5" (39 cm) |
| Freezer - Capacity | 2.47 cu.ft |
| Freezer - Shelf Type | Wire |
| Freezer - Shelf Qty | 4 |
| Thermostat Type | Digital |
| Fan Type | Interior |
| Freezer - Temperature Range | -30 to -10ºC |
| Freezer - Refrigerant Type | R290a |
| Freezer - Refrigerant Amount | 1.31 oz. |
