FARRAR ULC-328 138.25 Ultra-Low Chamber, 328 cu.ft. (9,288 L), +2°C to +8°C and -20°C to -80°C Temperature Range, Pallet Rack Internal Configuration, Air/Water Cooled Condenser Type, Automatic Defrost
FARRAR® pioneered forced air convection cooling to answer the challenge of preserving and storing biological and human tissue donor samples and materials. Purpose-built for life science applications, the Ultra-Low Chamber ULC-190, new ULC-259, and ULC-328 are the only +2°C to +8°C and -20°C to -80°C, forced air, ultra-low-temperature freezers on
the market.
Ideal for bulk commercial short and long-term needs, these innovative chambers offer rapid, efficient, and more sustainable product cool-down and accommodate universal product containers (all sizes—bags, bottles, boxes, etc. of pharmaceutical packaging).
With 190 cu. ft. / 5,380 liters up to 328 cu. ft. / 9,288 liters of storage, these solutions help optimize footprint requiring only 47 sq. ft. / 4.36 m2 of space. At +/-3.0°C, the units feature unmatched uniformity, offer fully redundant systems (control, refrigeration, airflow), and provide the fastest temperature recovery from door opening versus competitor offerings.
Features
- Integrated full redundancy (refrigeration, controls, electrical)
- Best temperature uniformity on the market (+/- 3.0°C)
- Low temperature deviation (+/- 1°C)
- Wide-range (+2°C to +8°C and -20°C to -80°C) forced air convection
- Optimized footprint
- Optional racking/shelving system available
- Optional material handling carts available
Benefits
-
Fastest temperature recovery from door opening
- HMI touchscreen provides visual temperature profile progress with export capability
- Universal container acceptance (all sizes—bags or bottles)
- Adjustable shelves available for process optimization
- Accommodates any configuration including hanging systems or Metro Shelving systems
- Available Internationally
- Plug-and-play installation
- Designed with frequent access storage, clinical trial kitting, and logistics prep process needs in mind
- Ergonomically engineered for high-density storage and pull/pack/ship accessibility
- Accommodates smart sliding racks and carts to minimize product/substance/sample handling
- Enables easy loading and pulling from the ground
- Intelligent drawer systems accommodate blood bag and cryo box upright ULT racking, shippable packaging, bottles, and single-use bags and shells
- Enables maximized storage density without sacrificing organization
Product Specifications
| APPLICATION AND ELECTRICAL REQUIREMENTS | Application | Pharmaceutical, Biopharmaceutical, Biorepository, Bio-Logistics |
| Chamber Volume | ULC-328 = 328 cu. ft. / 9,288 L | |
| Circuit Breaker | 2 x 30 amp | |
| Ambient Operating Temperature | +18°C to +30°C | |
| Temperature Range | +2°C to +8°C and -20°C to -80°C | |
| Electrical | North America: 208-230VAC, Single Phase, 60Hz | |
| International: 230VAC, Single Phase, 50Hz | ||
| STORAGE CAPACITY DIMENSIONS | Total Volume | 328 cu. ft. / 9,288 L |
| Area Footprint | 73.2 sq ft. / 6.8 m2 | |
| Interior Dimensions | 121 x 54 x 87 in (W x D x H) 3073.4 x 1371.6 x 2210 mm |
|
| Exterior Dimensions | 138.25 x 76.25 x 145.25 in (W x D x H) 3508 x 1936.7 x 3689.35 mm |
|
| Unit Weight | 3,900 lbs. / 1,769 Kg | |
| Shipping Weight | 4,500 lbs. / 2,132 Kg | |
| REFRIGERATION SYSTEM | Evaporator/QTY | Forced Air / (2) |
| Condenser/QTY | Forced Air-Cooled / (2) or Water-Cooled | |
| Metering Device | Electronic | |
| High Stage/ Low Stage | R-449A / R-508B | |
| Air Cooled Condenser | +18°C to +30°C | |
| Water Cooled Condenser | Tower Water 85°F (29.5°C), Max. flow rate 7gpm (26.5 l/min) | |
| Requirements | Chilled Water 45°F (7.2°C), Max. flow rate 3.5 gpm (13.25 l/min) | |
| PERFORMANCE DATA | Uniformity Air Temperature | +/- 3.0°C (empty chamber) |
| Temperature Control | +/- 1.0°C | |
| Warranty | 1 year parts and labor (North America) | |
| 1 year parts only (Outside of North America) | ||
| CONTROLLER | Temperature Controller/QTY | Microprocessor (2) |
| Displays (145mm) | LCD (2) | |
| Alarms | High/Low temperature, door ajar, power failure, remote alarm contacts | |
| Modbus TCP/IP | Communication Protocol | |
| Dry Contacts | Standard (C, NO, NC) | |
| Voltage (Hz) | Air-Cooled: 208-230VAC - 1 Phase - 60 Hz | |
| Water- Cooled: 208-230VAC - 1 Phase - 60 Hz | ||
| MATERIAL HANDLING SOLUTIONS | Palette Capacity | 4 - 40" (1016 mm) W x 48" ( 1219 mm) D x 36" ( 914 mm) H |
| Product Cart | 51 1/2" (1308 mm) D x 21" (534 mm) W x 61 1/2" (1562 mm) H, (4) Shelves 18" (457 mm) | |
| Transfer Cart | 41 1/16" (1043 mm) D x 39" (991 mm) W 45 1/8" (1146 mm) H |
