HABCO ESM10HC/ESM12HC 23.875" Impulse Cold Space Merchandiser, Single Glass Door, 1°C - 4°C, 10 or 12 cu. ft.

HABCO ESM10HC/ESM12HC 23.875" Impulse Cold Space Merchandiser, Single Glass Door, 1°C - 4°C Temperature Range, 10 or 12 cu. ft., Priority Air-Flow, Free&Clear™ Condenser, Front Breathing Refrigeration, LED Lighting System, NSF-7 Compliant

The HABCO Impulse Cold Space Merchandiser® is engineered for high-visibility retail locations, check-out lines, end-aisles, food court kiosks, and restaurant serving stations. Designed for maximum capacity with over-top visibility, this commercial unit features a space-saving design with exclusive front-breathing air ventilation that allows built-in installation on top, bottom, rear, and both sides. Equipped with a removable, bottom-mounted Cassette® forced-air refrigeration system running on eco-friendly R290 hydrocarbon refrigerant, it operates efficiently between 34°F and 39°F (1°C to 4°C).

The interior features NSF-approved white aluminum lining, a stainless steel floor, and brilliant LED lighting with backlit door merchandising on an independent switch. Heat-reflecting HABCO insulated safety glass and a self-closing swing door ensure energy efficiency while keeping products at optimal display temperatures. Factory-built with heavy-duty adjustable shelving, durable textured black exterior finish, and eco-conscious polyurethane insulation, this unit offers a robust, low-maintenance cooling solution for pre-packaged aseptic products.

Refrigeration

• Self contained Cassette® forced-air refrigeration employs R290 hydrocarbon Natural Refrigerant within a sealed capillary tube system.

• Cassette® refrigeration is bottom-mounted and removable from the front for ease of maintenance. Refrigeration may be exchanged or upgraded without mechanic. Designed to operate at a set point between 34°F and 39°F (1°C - 4°C).

• Priority, directed air flow provides optimum cooling and energy efficiency within cabinet and exclusively at front of unit for optimized heat exchange ventilation.

• Finless, Free&Clear™ Condenser Coil maximizes air-flow over the compressor, reduces energy consumption and is non-clogging.

• Automatic, stainless steel condensate control system.

• Quality, self-lubricating and sealed motors with streamlined air-flow provide quieter yet robust refrigeration.

Cabinet

• Exterior – durable textured black.

• Interior – NSF approved white aluminum liner with stainless steel floor.

• Ergonomic raised interior floor.

• Space Saving Design – air ventilation exclusively from the front of unit.

• Insulation – cabinet is foamed-in-place with eco-conscious, polyurethane insulation.

• Heavy duty thread-in leveler legs.

Doors

• Self-Closing Swing Door features hold-open position and spring-back protection, reversible on-location.

• Magnetic gaskets are single piece bead-mount construction easily removable for cleaning.

• Heat Reflecting HABCO Insulated Safety Glass with black extruded frame.

• Integrated, injection molded pocket handle(s).

Lighting

• LED Lighting System for Brilliant Illuminated Interior Display and Available Backlit Door Merchandising, on Switch.

Storage

• Three (3) white coated shelves 19 1/2"W x 18"D (496mm x 458mm), are NSF approved. (ESM10HC)
• Four (4) white coated shelves 19 1/2"W x 18"D (496mm x 458mm), are NSF approved. (ESM12HC)
• Heavy duty aluminum shelving pilasters will not peel or chip adjustment of 1/2" (13mm) increments.

• NSF-7 compliant for storage or display of pre-packaged aseptic product.

Electrical

• Factory power cord installed for connection to a sole-use (dedicated) 115V/60Hz/1-Phase, 15 Amp circuit.

Product Specifications

Standard delivery typically takes 5-7 business days
