Hoshizaki UR27B-LPD2 Low Profile Refrigerator, Single Section Undercounter, Stainless Drawers, Front-Breathing Airflow, Heavy-Duty Drawer Slides, Innovative Air Distribution, Eco-Friendly R290 Refrigerant
The UR27B-LPD2 Steelheart Series Undercounter single section low profile refrigerator with stainless drawers is a space saving workhorse. Engineered to maintain food safe temperatures in 100°F ambient conditions. With a net capacity of 6.21 cubic feet this efficient undercounter low profile refrigerator and front air flow design is perfect for hot/tight kitchens. The UR27B-LPD2 is constructed of stainless steel, which protects this unit from accidental damage and rust. Plus, it is easy to clean.
The UR27B-LPD2 also includes Drawers capacity: Top: (1) 12″ x 20″ full size pan and (2) 1/4 size pans. Bottom: (1) full size pan (pans by others), (4) 2.25″ stem casters (2 with brakes) are standard, plus the drawer slides are constructed of 14 gauge stainless steel with durable acetal rollers. Electrical consumption of 0.65 kWh/day at 3 Amps, 10 ft long cord with a 5 – 15P NEMA plug. Optional kits: 4″ or 6″ casters, Overshelves (single or double), Stainless steel back, Drawer divider bars (vertical or horizontal). The unit is ETL Safety (US & C) Listed, ETL Sanitation, ADA Compliant, Georgia Made Certified, ENERGY STAR® qualified, and includes a 7-7-7 Warranty (seven years labor, seven years parts, seven years compressor.
Features
- ADA-Compliant Compact Design: Measures 27″ W × 30″ D × 31.9″ H (including standard casters) to fit under lower ADA-height worktables.
- Front-Breathing Airflow: Requires no side or rear clearance, allowing flush installation against walls and adjacent equipment.
- Full Stainless Steel Construction: Features a heavy-duty stainless steel exterior (front, sides, top) and interior cabinet for durability and sanitation.
- Heavy-Duty Drawer Slides: Built with 14-gauge stainless steel drawer slides and smooth acetal rollers to support heavy food pans.
- Flush-Mount Handles: Extruded aluminum flush handles streamline the profile and prevent aisle interference.
- Innovative Air Distribution: Evenly distributes cold air throughout the 6.21 cu. ft. capacity interior to maintain consistent temperatures.
- Enamel-Coated Evaporator Coil: Extends coil life with superior protection against corrosion.
- High-Ambient Engineering: Designed to maintain food-safe temperatures even in severe 100°F ambient kitchen environments.
- Eco-Friendly R290 Refrigerant: Operates with natural R290 hydrocarbon refrigerant for low environmental impact.
- Optimized Drawer Capacity:
- Top Drawer: Holds (1) 12″ × 20″ full-size pan and (2) 1/4-size pans.
- Bottom Drawer: Holds (1) 12″ × 20″ full-size pan (pans sold separately).
- Thermal Insulation: Insulated with 2″ CFC-free, foamed-in-place polyurethane for thermal efficiency.
- Standard Mobility: Ships with (4) 2.25″ stem casters (2 with brakes).
- Electrical & Refrigeration Power: Powered by a 1/6 HP compressor (798 BTU/hr) on a 115V / 60Hz / 1-ph connection with a 10 ft. cord and NEMA 5-15P plug.
- Shipping Dimensions & Weight: Ships in a crate measuring 34″ L × 31.5″ D × 35.5″ H with a total weight of 203 lbs.
- Optional Field Accessories: Compatible with optional 4″ or 6″ casters, single/double overshelves, stainless steel back panel, and horizontal or vertical drawer divider bars.
- Industry-Leading 7-7-7 Warranty: Backed by a 7-year parts, 7-year labor, and 7-year compressor warranty.
Specifications
| Pruduct Overview | Details |
| Model | UR27B-LPD2 |
| Series | Steelheart Series |
| Dimensions (W × D × H) | 27″ × 30″ × 31.9″ (includes 2.25″ casters) |
| Depth with Drawer Fully Extended | 51″ D |
| Drawer Opening Dimensions | 22.75″ W × 23″ H |
| Nominal / Interior Storage Capacity | 6.21 cu. ft. |
| Number of Drawers | 2 |
| Drawer Pan Capacity |
Top: (1) 12″ × 20″ Full-Size Pan & (2) 1/4-Size Pans Bottom: (1) 12″ × 20″ Full-Size Pan |
| Electrical Connection | 115V / 60Hz / 1-ph, 10 ft. Cord with NEMA 5-15P Plug |
| Amperage | 3.0 A |
| Max Fuse / HACR Breaker | 15 A |
| Energy Consumption | 0.65 kWh/day |
| Compressor Power | 1/6 HP (Nominal 798 BTU/hr) |
| Heat Rejection | 152 BTU/hr |
| Refrigerant | R290 Hydrocarbon |
| Ambient Temperature Range | 45°F – 100°F |
| Voltage Range | 104V – 126V |
| Control Setpoint Range | 32°F – 52°F |
| Construction | Stainless Steel Exterior (front, sides, top) & Stainless Steel Interior |
| Drawer Slides | 14-Gauge Stainless Steel with Acetal Rollers |
| Insulation | 2″ CFC-Free Foamed-in-Place Polyurethane |
| Casters | (4) 2.25″ Stem Casters (2 with brakes) |
| ADA Compliant | Yes (31.9″ Height) |
| Shipping Crate (L × D × H) | 34″ × 31.5″ × 35.5″ |
| Shipping Weight | 203 lbs |
| Warranty | 7-Year Parts / 7-Year Labor / 7-Year Compressor |
