Merits P326D0ARMUB VISION SPORT W/ LIFT W/ 6.5" POWER SEAT LIFT, 16",18", CAPTAIN or PAN SEAT,RED
SKU: P326D0ARMUB
Free Shipping
Regular price $4,799.00 $3,723.00 22% off
Unit price
per
Product
P326D
Weight Capacity
300 lbs.
Drivetrain
MWD
Seat Type
Captain or Pan
MeritsSKU P326D0ARMUB

Merits P326D0ARMUB VISION SPORT W/ LIFT W/ 6.5" POWER SEAT LIFT, 16",18", CAPTAIN or PAN SEAT,RED

Product
P326D
Weight Capacity
300 lbs.
Drivetrain
MWD
Seat Type
Captain or Pan
Regular price $4,799.00 $3,723.00
Unit price
per
Save $1,076 (22%)
Free shipping
Availability

?
Inventory levels are dynamic and subject to change due to high demand.
(0 in cart)
SSL SecureSecure Checkout Secure Checkout
  • Fast & reliable shippingShipping cost is calculated and confirmed at checkout.
  • Regulatory compliantRegistered & certified medical equipment
  • Best price guaranteeFind it cheaper? We'll match it.
  • Need help choosing?Call +1-973-858-5049 or contact us
Request a quote

Product
P326D
Weight Capacity
300 lbs.
Drivetrain
MWD
Seat Type
Captain or Pan

Overview

From the manufacturer

Features :

• • True mid-wheel: 20”turning radius

• Toggle lift operation or upgrade through the joystick (E2310)

• VR2 joystick is programmed via PP1 programmer

• Premium, semi-reclining ergonomic seat up to 135°

• 10” solid tires for superior traction

• 16” - 20” customizable seat depth

• 6.5” power elevating seat



Product

Specifications

Manufacturer data. Imperial with metric in brackets.

Product
P326D
Weight Capacity
300 lbs.
Drivetrain
MWD
Seat Type
Captain or Pan
Seat Width
16"or 18” or 20”
Seat Depth
16” - 20”
Backrest Height
20”
Seat-to-Floor Height
 20.5” - 29.5”
Seat Elevation
6.5”
Overall Length
34”
Overall Width
24”
Overall Height
48.5”
Turning Radius
20”
Ground Clearance
2”
Total Weight
214 lbs.
Wt of Heaviest Pc.
120 lbs.
Max Speed
5 mph
Range Per Charge
up to 18 mi.
Motor
 DC24V / 160W
Controller
P&G VR2 60A
Battery Size
(2 required) 35Ah, 12V, U1
Charger
4A off-board
Gradient
6°
Front Wheels
6” - solid
Drive Wheels
10” - solid
Rear Wheels
6” - solid
HCPCS Codes
K0830 / K0831
Color Options
Red
