| Overview | |
|---|---|
| Product Name | Powerline BSG10X Multi-Station Gym |
| Product Model | BSG10X |
| Brand / Product Line | Powerline by Body-Solid |
| Product Category | Single-Stack Compact Multi-Station Gym |
| Commercial Rating | In-Home Rated |
| Weight Stack Configuration | 160.00 lbs. (72.57 kg) Selectorized Stack |
| Resistance Ratio | 1:1 Ratio on Upper Pulley, Mid Pulley, Low Pulley, and Press Station |
| Frame Construction | 14-Gauge Steel Mainframe |
| Frame Finish | Scratch-Resistant Electrostatically Applied Powder Coat |
| Cables & Pulleys | 2,200 lb. Aircraft Cable with Swiveling Ends; Fiberglass Reinforced Nylon Pulleys |
| Ergonomics | Chrome-Plated Telescoping Adjustable Seat Post |
| Included Accessories | 48" Lat Bar, Low Row Bar, Ab Crunch Harness |
| Warranty (In-Home) | Frame & Welds: 10 Years; Bushings & Hardware: 1 Year; Pads, Rollers, & Grips: 1 Year |
| Station Breakdown | |
| Adjustable Press Arm | 8-Position Chest Press, Incline Press, Chest-Supported Mid-Row |
| Lat Pulldown / High Pulley | Lat Pulldowns (Unilateral/Bilateral/Converging/Diverging), Triceps Pressdowns |
| Ab Crunch / Mid Pulley | Resistance Ab Crunches, Overhead Triceps Extensions |
| Low Pulley Station | Seated Rows, Cable Biceps Curls, Upright Rows, Cable Shrugs, Leg Adduction/Abduction |
| Leg Developer Station | Cam-Driven Leg Extension & Seated Leg Curl |
| Optional Attachment | BSGLPX Leg Press Attachment (Sold Separately) |
| Dimensions & Weights | |
| Assembled Product Dimensions | 66.00" L x 47.00" W x 80.00" H (1,676.40 mm L x 1,193.80 mm W x 2,032.00 mm H) |
| Working Frame Area Dimensions | 70.00" L x 42.00" W x 80.00" H (1,778.00 mm L x 1,066.80 mm W x 2,032.00 mm H) |
| Assembled Total Weight | 316.00 lbs. (143.34 kg) / Shipping Document Weight Note: 328.00 lbs. (148.78 kg) |
| Package Dimensions | 81.89" L x 27.56" W x 13.39" H (2,080.01 mm L x 700.02 mm W x 340.11 mm H) |
| Package Gross Weight | 191.40 lbs. (86.82 kg) (Main Frame Box) + Selectorized Weight Stack Boxes |
Typically 1-3 Business Days
Registered & Certified Medical Equipment
Need help?
Typically 1-3 Business Days
Registered & Certified Medical Equipment
Need help?
Powerline BSG10X Multi-Station Gym, 90% Pre-Assembled Construction, 8-Position Adjustable Press Arm, Triple Pulley System, No-Cable-Change System
The Powerline BSG10X Multi-Station Gym (SKU: BSG10X) by Body-Solid is engineered for rapid assembly, compact footprint efficiency, and full-body strength conditioning. Arriving 90% pre-assembled in a single box with factory-strung cables and pre-installed pulleys, the BSG10X can be set up in under 30 minutes using a simple 9-bolt process. Its compact frame—measuring under 4 feet wide and 6.5 feet tall—fits comfortably into tight home spaces without sacrificing workout performance.
Powered by a 160 lb. selectorized weight stack operating at a 1:1 resistance ratio across all stations, the BSG10X supports over 40 distinct exercises. It features an 8-position adjustable chest press arm, high/mid/low cable pulleys, an integrated leg developer, and a no-cable-change routing design that keeps workout momentum seamless.
Features:
- 90% Pre-Assembled Construction: Factory pre-hung cables and pulleys allow rapid setup using a simple 9-bolt assembly process.
- 160 lb. Selectorized Weight Stack: Standard 160 lb. (73 kg) stack provides 1:1 resistance across upper pulley, mid pulley, low pulley, and press arm stations.
- 8-Position Adjustable Press Arm: Biomechanically designed chest press arm adjusts across 8 positions for chest pressing, incline pressing, and chest-supported mid rows.
- Triple Pulley System: High, Mid, and Low pulleys support lat pulldowns, resistance ab crunches, cable curls, seated rows, upright rows, and deltoid raises.
- Integrated Leg Developer: Provides biomechanically aligned leg extensions and seated leg curls.
- No-Cable-Change System: Streamlined cable routing allows immediate transitions between exercises without cable re-routing or pin swaps.
- Durable Frame & Components: Constructed with a 14-gauge steel mainframe, 2,200 lb. tension-rated aircraft cables with swiveling ends, and fiberglass-reinforced nylon pulleys with steel ball bearings.
- Ergonomic Adjustability: Features a chrome-plated telescoping seat post and contoured pads to accommodate users of all heights.
- Included Accessories: Ships complete with a 48" lat bar, low row bar, and ab crunch harness.
- Optional Leg Press Compatibility: Compatible with the optional BSGLPX Leg Press Attachment for dedicated lower-body strength training.
- 10-Year In-Home Warranty: Backed by Powerline's 10-year warranty on frame and welds, with 1-year coverage on bushings, hardware, pads, rollers, and grips.
Specifications:
