Quincy Lab 10AFE-LT Digital Air Forced Convection Low Temp Lab Oven
Quincy Lab 10AFE-LT Digital Air Forced Convection Low Temp Lab Oven
Quincy Lab 10AFE-LT Air Forced Convection Digital Low Temperature Oven, 0.6 Cubic feet, Maximum 225°F, (107°C), 440W
'AFE-LT' (Digital Air Forced Low Temperature), Lab Ovens series are designed to meet the laboratory needs of industry, research organizations and schools.
Well-crafted and versatile, they are used for part drying, baking, curing, sterilizing, evaporating, heat treating, annealing, and testing.
The Quincy 10AFE-LT has a capacity of 0.6 cubic feet and a temperature range of +15°F to 225°F 107°C.
- AFE-LT Models - Quincy Lab uses only quality UL and CSA recognized components in all ovens. The 'AFE-LT' models offer forced-air circulation allowing for uniform distribution of heat throughout the chamber, which also facilitates dehydration and evaporating. The AFE-LT series ovens have a temperature range of 225°F/107°C, and are competitively priced and offer exceptional value and reliability.
AFE-LT Series Temperature Range
Ambient +15°F minimum to a maximum of 225°F (107°C).
Oven Features
Although there are several different models and styles, all of our Digital Lab Oven Series offer these standard features:
- Digital PID microprocessor
- Accuracy of ±0.5°C
- Dual overtemperature safety feature
- Corrosion resistant aluminized interior
- 115 Volts & 230 Volts available
- Resistive-tubular incoloy heating elements
- 1" inch of high density mineral wool insulation
- Insulated Steel Doors with high impact thermoplastic handles
- 2 adjustable and 1 fixed nickeled plated shelves
- Baked in scratch-resistant powder coated finish
- A circulating fan which provides air circulation for improved uniformity (AF Models only)
Digital PID microprocessor
Provides not only ease of use but maintains an accuracy of ±0.5°C allowing for the most demanding applications.
Dual Over temperature safety
Our digital ovens offer both an electronic fail safety alarm and a secondary thermos fail safety alarm which will shut-off the unit until it is manually reset.
Product Specifications:
| MODEL | 10AFE-LT |
| INTERIOR DIMENSIONS | |
| Inches W x H x D | 12x8.25x10 |
| (cm) W x H x D | 30.5x21x25.4 |
| EXTERIOR DIMENSIONS | |
| Inches W x H x D | 14x20.5X12.3 |
| (cm) W x H x D | 35.6x52x31.2 |
| CAPACITY | |
| Cubic feet | 0,6 |
| Liters | 17 |
| ELECTRICAL | |
| Volts / Amps | 115 / 3.65 |
| Watts | 440 |
| Frequency (Hz) | 5-15P |
| PERFORMANCE | |
| Control Stability at 100°C | |
| Typically ± °C / °F | 1.0°C / 0.5°C |
| Time to temp. | |
| AMBIENT TO MAX | 36 Min. |
| Recovery time at 200°F | |
| Door opened 15 sec. | 3min. |
| Door opened 30 sec. | 4min. |
| Weight (lbs.) | |
| Shipping / alone | 44/38 |
| Shelves | |
| MAXIMUM PER UNIT | 8 |
| MAXIMUM POUNDS / SHELF | 35 |
| TEMPERATURE RANGE | |
| Ambient + 15 F to: F / C | 225/107 |
