SCILOGEX 873032419999 SCI220-H3/H5 LCD Digital Magnetic Stirring Heated Water Bath with 3L/5L Capacity Options for Precise Lab Heating & Stirring
SCILOGEX’s 873032419999 SCI220-H3/H5 LCD Digital Magnetic Stirring Heated Water Bath is a versatile, dual-function lab device for precise heating (up to 220°C) and stirring (100-1500 rpm) of samples in flasks or tubes, ideal for chemical synthesis, enzyme reactions, and bacterial growth in biotech, clinical, and research settings. Choose 3L or 5L bath capacities with high borosilicate glass liner and window for monitoring, brushless DC motor for quiet operation, and LCD display for real-time speed/time/temperature. Features timer (1 min - 99 hrs 59 min), reversible stirring, and protections (dry burning, over-current, ground fault, over-temperature). Residual heat warning (>50°C) and IP21 rating ensure safety. Compact (13.5" x 8.5" x 11.1", 6kg); made in China with a 2-year warranty for reliable, maintenance-free performance.
Features:
- High borosilicate glass liner with window for monitoring reaction product changes
- Dual-use stirring bath for water and oil, with optional stirring in the bath ensuring uniform heating of both bath liquid and sample
- Features a timer function with a range of 1 min to 99h 59min; heating continues when countdown ends but continues stirring to prevent heat damage to the sample
- Touch buttons with audible prompts; working status indicator light: Green during operation, flashing green before reaching set temperature; alarm red
- Reversible stirring function for enhanced mixing
- Protection features: dry burning protection, over-current protection, ground fault protection, and over-temperature protection
- Residual heat warning function; when plate temperature >50°C, heating is turned off, and screen flashes "HOT" as reminder
- DC brushless motor, spark-free, long life; low noise, maintenance-free, stable operation
- LCD displays speed, time, and temperature parameters clearly and intuitively
Specifications:
| Specification | Details |
|---|---|
| Heating Pan Material | High Borosilicate Glass + Stainless Steel Base |
| Motor Type | Brushless DC Motor |
| Stirring Positions | 1 |
| Max Stirring Quantity (H₂O) | 3L (H3 Variant); 5L (H5 Variant) |
| Max Magnetic Bar | 40mm Length |
| Speed Range | 100-1500 rpm (±10 rpm) |
| Speed Display | LCD |
| Temperature Display | LCD |
| Heating Temperature Range | Room Temp. - 220°C |
| Heating Liquid Temperature Control Accuracy | ±1°C |
| Overheating Temperature Protection | 350°C |
| Temperature Display Accuracy | 0.1°C |
| External Temperature Sensor | PT1000 |
| Buzzer | Yes |
| Positive and Negative Rotation | Yes |
| Protection Class | IP21 |
| Motor Rating Output | 20W |
| Heating Output | 850W (H3); 1000W (H5) |
| Power | 900W (H3); 1050W (H5) |
| Voltage/Frequency | 100-120V, 60Hz, US Plug |
| Bath Size | Ø220 x 105mm (H3); Ø220 x 150mm (H5) |
| Maximum Flask Volume | 3L (H3); 5L (H5) |
| Dimensions (W x D x H) | 13.5" x 8.5" x 11.1" (343 x 215 x 283 mm) |
| Weight | 6.0 kg |
| Timer Function | 1 min - 99 hrs 59 min |
| Permissible Ambient | 5-40°C, 80% RH |
Variants:
| Variant | Description | SKU |
|---|---|---|
| 3L Capacity | SCI220-H3 LCD Digital Magnetic Stirring Heated Water Bath, 3L Capacity | 873032419999 |
| 5L Capacity | SCI220-H5 LCD Digital Magnetic Stirring Heated Water Bath, 5L Capacity | 873033419999 |
Contents:
| Description | Quantity |
|---|---|
| Selected SCI220-H Series LCD Digital Magnetic Stirring Heated Water Bath Unit | 1 |
| Power Cord (US Plug) | 1 |
| User Manual | 1 |
