- 16-inch SENZA™ Touchscreen
- AnyCast screen mirroring technology
- Horizontal and vertical seat adjustment
- Fingertip and toggle controls for easy resistance adjustment
Product Specifications
| Unit Weight | 222.2 lbs / 101 kg |
| Dimensions (LxWxH) | 49.7 x 27 x 59.1 in / 126.1 x 68.5 x 150.1 cm |
| Resistance | 40 levels |
| Max User Weight | 500 lbs / 227.3 kg |
| Power Requirements | 100V-120V / 60Hz-50Hz* 200V-240V / 50Hz-60Hz |
| Plug Requirements | NEMA 5-15* | Contact your sales rep for specific requirements |
| Features | Console toggles and fingertip controls for easy resistance adjustment |
| Multi-point seat adjustment | |
| 3 Speed fan | |
| Optional Features | SA Well+™ Integration |
Touchscreen Technical Details
| Screen | TFT Backlit LED Capacitive Touchscreen w/ Anti-Glare |
| Resolution | 1366 x 768 |
| Screen Size | 16 in |
| Aspect Ratio | 16:09 |
| Operating System | Android 5.1.1 |
| Contrast ratio | 500:01:00 |
| Processor | NXP Freescale I.MX6 Quad Core, 1GHz |
| Memory | 32GB eMMC |
| Languages | English, Traditional Chinese, Simplified Chinese, Japanese, German |
| System Updates | Manual USB or Push (via Wi-fi opt-in) |
| Brightness | 15 Adjustable Settings (300 cd/m2) |
| Viewing Angle | 160° Vertical & Horizontal |
| Connectivity | Wi-fi (IEEE 802.11 a/b/g/n) | LAN Ethernet (10/100Mbps) |
| Web Browsing | Closed browser, owner/operator determines web page availability |
| TV Support | ATSC / QAM(64,256) / NTSC | DVBT / PAL / SECAM |
| Inputs | AV (CVBS) | Coax |
| Readouts | Resistance, Stride length, Time, Heart rate, Distance, Calories, Strides per minute |
| Workout | Programs Manual, Random, SENZA™ Journey, Interval, Plateau, Fat Burn, Track, Fitness Test, Heart Rate |
| Features | Bluetooth 4.0 heart rate support |
| Bluetooth-AVRCP iOS & Android music compatible | |
| Customizable home screen logo, embedded url on home screen, screen saver images & web pages | |
| 13 SENZA™ Journeys |
Warranty
| Type | Full Commercial - no usage limit |
| Frame | Lifetime (7 years) |
| Parts | 5 Years |
| Wear Items | 5 Years |
| Labor | 3 Years |
| High Wear Items | 90 days, no labor |
| SENZA™ Touchscreen | 2 Years |
