Summit BIM18SS 18" Compact Built-In Ice Maker — Front-Breathing Frost-Free Design with 304 Stainless Steel Door and No-Drain Installation
The Summit BIM18SS is a built-in capable ice maker designed for smaller kitchens and ADA-compliant installations. Measuring just under 18 inches wide, this unit features a front-breathing design that allows for seamless integration under counters or freestanding placement. The fully wrapped 304 grade stainless steel door and professional-style handle deliver a commercial-grade appearance suitable for residential or light clinical environments.
With a daily ice production and storage capacity of 8 lbs., the BIM18SS generates crescent-shaped ice cubes in a removable bucket for easy cleaning and transport. The unit requires no drain or pump, offering flexible installation options in compact spaces. Frost-free operation eliminates manual defrosting, reducing maintenance demands in high-use settings.
Construction and Installation
The BIM18SS is built with a black cabinet and a user-reversible stainless steel door, allowing customization of door swing to suit layout requirements. A factory-installed keyed lock provides optional security, with two keys included. Additional chrome shelves accommodate frozen storage beyond ice, enhancing utility in multi-purpose environments.
Key Features
- Built-in capable design with front-breathing airflow for under-counter installation or freestanding use
- No pump or drain required for operation — simplifies placement and installation
- Produces and stores up to 8.0 lbs. of crescent-shaped ice cubes daily
- 304 grade stainless steel wrapped door with user-reversible swing and professional-style handle
- Factory-installed keyed lock for secure interior access (2 keys included)
- Removable ice bin for fast and easy cleaning
- Digital thermostat with electronic controls and temperature display in Celsius or Fahrenheit
- Frost-free operation eliminates manual defrosting and reduces user maintenance
- Adjustable chrome shelves included for storage of additional frozen items
- ETL and ETL-C certified for electrical safety in U.S. and Canadian installations
- Interior and exterior fan types with R600a refrigerant (1.06 oz.)
- 1-year parts and labor warranty; 5-year compressor warranty
Product Specifications
| Nominal Height | 35.0" (89 cm) |
| Height of Cabinet | 34.25" (87 cm) |
| Nominal Width | 18.0" (46 cm) |
| Width | 17.75" (45 cm) |
| Nominal Depth | 24.0" (61 cm) |
| Depth | 24.0" (61 cm) |
| Depth with Handle | 25.75" (65 cm) |
| Depth with door at 90° | 40.0" (102 cm) |
| Capacity | 2.7 cu.ft. (76 L) |
| Defrost Type | Frost-Free |
| Door | Stainless Steel |
| Cabinet | Black |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Amps | 1.1 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 82.0 lbs. (37 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101063706 |
| Door Swing | RHD |
| Reversible | Yes |
| Daily Ice Production | 8.0 lbs. (4 kg) |
| Ice Storage Capacity | 8.0 lbs. (4 kg) |
| Ice Shape | Crescent |
| Number of Ice Cube Sizes | 1 |
| Interior Light | Yes |
| Fan Type | Interior and Exterior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 1.06 oz. |
| High Side PSI | 270.0 |
| Low Side PSI | 103.0 |
| Interior Height | 23.5" (60 cm) |
| Interior Width | 12.75" (32 cm) |
| Interior Depth | 16.75" (43 cm) |
| Compressor Step Height | 4.5" (11 cm) |
| Compressor Step Width | 12.75" (32 cm) |
| Compressor Step Depth | 4.5" (11 cm) |
| Level Legs | 4 |
| Temperature Range | -22 to 14ºF |
