Summit BIM18SSADA, 18" ADA-Height Built-In Ice Maker with No-Drain Convenience and 8 lb Daily Production
The Summit BIM18SSADA is a compact built-in ice maker engineered specifically for ADA compliant installations, measuring just under 32 inches in height for seamless placement under lower counters. Featuring a 304-grade stainless steel wrapped door with a professional handle and factory-installed keyed lock, this unit delivers both style and security. Designed for ease of installation, it requires no drain or pump, offering exceptional flexibility in positioning within medical offices, therapy centers, assisted living facilities, and compliant kitchen environments.
This frost-free ice maker produces up to 8 lbs. of crescent-shaped ice cubes daily and stores them in a removable bucket for quick access and easy cleaning. Additional chrome shelving accommodates supplementary frozen items, while the digital thermostat and display provide precise temperature management with readouts available in Celsius or Fahrenheit. Its user-reversible door swing and eco-friendly R600a refrigerant further enhance adaptability and environmental responsibility.
Features:
- ADA compliant — Sized just under 32" high for installation under lower ADA compliant counters
- Built-in capable — Make the best use of space by installing your appliance under the counter
- No pump or drain required — Convenient design allows more flexibility in positioning the unit
- Ice production — Makes and stores up to 8 lbs. of crescent cubes
- Stainless steel door — Fully wrapped in stainless steel for a professional look
- Factory installed lock — Keyed lock for a secure interior (2 keys included)
- Removable bin — Bucket can be removed for fast and easy cleaning
- Digital thermostat — Electronic controls for precise temperature management
- Digital display — Temperature readout can be shown in Celsius or Fahrenheit
- Frost-free operation — Eliminates the need to manually defrost the interior
- Reversible door — User-reversible door swing for added flexibility
- CARB Compliant — Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
Specifications:
| Nominal Height | 32.0" (81 cm) |
| Height of Cabinet | 31.38" (80 cm) |
| Nominal Width | 18.0" (46 cm) |
| Width | 17.75" (45 cm) |
| Nominal Depth | 24.0" (61 cm) |
| Depth | 24.0" (61 cm) |
| Depth with Handle | 25.75" (65 cm) |
| Depth with door at 90° | 40.0" (102 cm) |
| Capacity | 2.7 cu.ft. (76 L) |
| Defrost Type | Frost-Free |
| Door | Stainless Steel |
| Cabinet | Black |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Amps | 1.1 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 82.0 lbs. (37 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101063713 |
| Door Swing | RHD |
| Reversible | Yes |
| Daily Ice Production | 8.0 lbs. (4 kg) |
| Ice Storage Capacity | 8.0 lbs. (4 kg) |
| Ice Shape | Crescent |
| Number of Ice Cube Sizes | 1 |
| Interior Light | Yes |
| Fan Type | Interior and Exterior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 1.06 oz. |
| High Side PSI | 270.0 |
| Low Side PSI | 103.0 |
| Interior Height | 23.5" (60 cm) |
| Interior Width | 12.75" (32 cm) |
| Interior Depth | 16.75" (43 cm) |
| Compressor Step Height | 4.5" (11 cm) |
| Compressor Step Width | 12.75" (32 cm) |
| Compressor Step Depth | 4.5" (11 cm) |
| Level Legs | 4 |
| Temperature Range | -22 to 14ºF |
