| Overview | |
|---|---|
| Product Name | VWR Plus Series Refrigerator Freezer Combo Unit (-30°C Freezer) |
| VWR Catalog No | 76488-180 |
| Model Code | HCRFC1030 |
| Supplier | VWR International |
| Total Capacity | 9.2 cu. ft. total (5.2 cu. ft. / 147 L Refrigerator; 4.0 cu. ft. / 113 L Freezer) |
| Door Type | 2 solid swing doors (1 refrigerator, 1 freezer) |
| Defrost System | Cycle defrost (Refrigerator); Manual defrost (Freezer) |
| Shelves | 3 adjustable shelves (Refrigerator); 3 adjustable shelves + 1 bottom footed shelf (Freezer) |
| Control System | Dual microprocessor controllers with exterior digital displays |
| Security | Keyed door locks on both doors |
| Alarms | Audible and visual high/low temperature alarms, remote alarm contacts |
| Probes | Dual probes (1 air probe, 1 sample bottle probe) |
| Probe Access | 3/8" probe access port |
| Lighting | Interior LED light (Refrigerator compartment) |
| Cabinet Exterior | White powder-coated cabinet and doors |
| Insulation | High-density urethane foam cabinet and door insulation |
| Mounting & Setup | Leveling legs and stacking kit included |
| General Warranty | Two-year parts and labor warranty |
| Compressor Warranty | Three-year additional compressor parts warranty |
| Certifications & Compliance | UL/C-UL Listed, HFC-free, Environmentally Preferable (Safer Human & Environmental Health, Energy Efficient) |
| Physical Dimensions & Weight | |
| Exterior Dimensions (W x D x H) | 23.75" x 24.00" x 65.00" (603 x 610 x 1651 mm) |
| Refrigerator Interior Dimensions (W x D x H) | 19.875" x 16.00" x 26.75" (505 x 406 x 679 mm) |
| Freezer Interior Dimensions (W x D x H) | 17.625" x 15.875" x 24.875" (447 x 403 x 632 mm) |
| Required Clearance | 4" clearance on sides and back for adequate ventilation |
| Shipping Weight | 122 kg (268 lbs.) |
| Performance & Electrical Details | |
| Refrigerator Operating Temperature | 2°C to 8°C |
| Freezer Operating Temperature | -27°C to -33°C (-30°C nominal) |
| Compressor Power | 1/6 HP (Refrigerator); 1/4 HP (Freezer) |
| Refrigerant | HFC-free R600a (Refrigerator); Natural R290 Hydrocarbon (Freezer) |
| Electrical Requirements | 115 V / 60 Hz; 1.3 A (Refrigerator), 2.2 A (Freezer) |
New
VWR HCRFC1030 Plus Series Refrigerator Freezer Combo Unit Dual Microprocessor Keyed Lock (-30°C Freezer), 5.2 cu. ft.
SKU: HCRFC1030
Fast & Reliable Shipping
Typically 1-3 Business Days
Regulatory Compliant
Registered & Certified Medical Equipment
Support
Need help?
Fast & Reliable Shipping
Typically 1-3 Business Days
Regulatory Compliant
Registered & Certified Medical Equipment
Support
Need help?
VWR HCRFC1030 Plus Series Refrigerator Freezer Combo Unit Dual Microprocessor Keyed Lock (-30°C Freezer), 5.2 cu. ft. Refrigerator / 4 cu. ft. Freezer, Optimized Defrosting Systems
The VWR Plus Series Freestanding Refrigerator Freezer Combination Unit (Catalog No: 76488-180 / Model: HCRFC1030), supplied by VWR International, is a high-performance dual-temperature cold storage solution engineered for laboratory settings requiring low-temperature (-30°C) frozen preservation alongside standard refrigerated storage. Combining a 5.2 cubic foot (147 L) refrigerator compartment with a 4.0 cubic foot (113 L) low-temperature freezer compartment, this compact freestanding cabinet delivers precise dual microprocessor control, robust security, and eco-friendly performance.
Designed for demanding scientific and clinical workflows, the unit features a dual-door setup consisting of two solid swing doors with recessed door handles, magnetic gaskets for positive sealing, and independent keyed door locks to secure stored samples. The durable white cabinet structure is insulated with high-density urethane foam and equipped with leveling legs and a stacking kit setup for structural stability.
Temperature management is driven by independent microprocessor controllers paired with digital displays for both compartments. The upper refrigerator compartment operates within a 2°C to 8°C range utilizing forced draft air circulation and an automated cycle defrost mechanism. The lower freezer compartment maintains ultra-stable low temperatures between -27°C and -33°C (-30°C nominal) with a manual defrost design to preserve critical biological samples without defrost temperature spikes. Both compartments feature comprehensive monitoring with audible/visual high and low temperature alarms, dual sensing probes (air probe and sample bottle probe), remote alarm contacts, and a 3/8" probe access port.
Interior storage includes three adjustable shelves in the refrigerator compartment and three adjustable shelves plus a bottom footed shelf in the freezer compartment to maintain optimal air circulation. Interior LED lighting illuminates the refrigerator space for rapid inventory access. Powered by natural hydrocarbon refrigerants (HFC-free R600a for the refrigerator and natural R290 for the freezer), this system delivers high energy efficiency with zero ozone depletion potential.
Features:
- Low-Temperature Dual Storage: Integrates a 5.2 cu. ft. refrigerator (2°C to 8°C) and a low-temperature 4.0 cu. ft. freezer (-27°C to -33°C) in a space-saving freestanding footprint.
- Independent Microprocessor Controllers: Features separate digital controls and temperature displays for precise management of each compartment.
- Comprehensive Dual-Probe Alarm System: Equipped with audible/visual high and low temperature alarms, dual probes (air and sample bottle), remote alarm contacts, and a 3/8" probe access port.
- Independent Keyed Door Locks: Both solid swing doors feature physical keyed locks for dual-compartment sample security.
- Optimized Defrosting Systems: Automated cycle defrost for the refrigerator section and manual defrost for the freezer section to eliminate temperature fluctuations.
- Dual Hydrocarbon Refrigerant System: Utilizes HFC-free R600a for the refrigerator and natural R290 for the freezer to ensure low energy consumption and environmentally friendly performance.
- Flexible Interior Organization: Features 3 adjustable shelves in the refrigerator compartment and 3 adjustable shelves with a bottom footed shelf in the freezer compartment.
- Safety & Compliance: UL and C-UL listed design backed by a 2-year parts and labor warranty plus a 3-year additional compressor parts warranty.
Specifications:
